60SWA系列永磁无刷直流电机技术参数：
|
标准型号 Part Number |
Unit |
60SWA01 |
60SWA02 |
60SWA03 |
|
额定力矩 Rated Torque |
N.m |
0.38 |
0.6 |
0.75 |
|
转动惯量 Rotor Inertia |
g.cm2 |
0.09 |
0.17 |
0.28 |
|
总长度 Total Length |
mm |
84.5 |
105.5 |
126.5 |
|
重量 Weight |
Kgs |
0.85 |
1.05 |
1.25 |
|
不同绕线参数 Winding Option |
Unit |
01L2 |
02L3 |
03L4 |
|
额定电压 Rated Voltage |
V |
24 |
36 |
48 |
|
空载转速 No load Speed |
rpm |
3000 |
3250 |
3000 |
|
空载电流 No load Current |
A |
0.8 |
1 |
0.75 |
|
额定转速 Rated Speed |
rpm |
2500 |
2600 |
2500 |
|
额定电流 Rated Current |
A |
6 |
6.5 |
6.4 |
|
额定功率 Rated Output |
W |
99 |
163 |
215 |
|
反电势常数 Back Emf |
V/Krpmpm |
8 |
11 |
16 |
